Sides S3X Fire Engine



You can view the items you want quotes on by clicking on the 'View Selected Items' button above


Sides S3X Fire Engine Item Ref:116
Ref: 116



Sides S3X Fire Engine

Airport Ground Equipment – The Sides S3X Fire Engine is a high-performance airport rescue and fire fighting vehicle designed for rapid emergency response in demanding airside environments.

The Sides VMA S3X Sentinel 6×6 ARFF fire engine is engineered to deliver exceptional off-road capability, high-capacity firefighting systems, and advanced crew safety features while complying with international aviation and ICAO standards.

Specifications
Specification Details
Manufacturer Sides
Model VMA S3X (SENTINAL) 6×6 ARFF Fire Engine
Application Fire and Rescue
Year 2014
Specification Auto Gearbox Water tank capacity 10,000ltrs Foam tank capacity 1,000ltrs
Pump Output 6,000 litres at 12 bar

Foam expansion ration 7 to 10 depending on foam concentrate

Roof Monitor

Operating pressure 13 Bar
Output 1/1 4,500 l/min
Output 1/2 2,250 l/min
Range 70m
BumperMonitor

Operating pressure 13 Bar
Output 1/1 1,140 l/min
Range 55m
Foam expansion ration 3 to 4 depending on foam concentrate

Foam Hose Reel Hand Line

Default operating pressure 8 Bar
Flow rate 360 l/min
Range 25m depending on flow rate and adjustment of jet
Length 30m
Diameter 35mm

Foam Side Line

Default operating pressure 8 Bar
Flow rate 360 l/min
Range 25m depending on flow rate and adjustment of jet
Length 30m
Diameter 35mm

Vehicle Self Protection

Total flow rate 300 l/min
Radius range 3.50m

In excellent condition

Why Choose This Airport Ground Equipment?

Selecting proven airport ground equipment ensures safe aircraft operations, reduced downtime, and long-term cost efficiency. This unit represents a reliable solution for modern airport environments worldwide.

Condition Report
We offer equipment either:
  • As received from the relevant authority with a workshop check to make sure it operates but no reparatory works (AS IS) or
  • Fully prepared including servicing of all major components and a fresh coat of paint (PREPARED)
Delivery & Export

Worldwide delivery available.

Any item which is military by design or has component parts designed for military use will require an export license to be applied for if being exported from the United Kingdom,
